RANGER FL 235 JN
SPESIFIKASI
PRODUK | Model | FL 235 JN |
PRODUKSI | Kode Produksi | FL8JNKA-GGJ |
PERFORMANCE | Kecepatan Maksimum(km/jam) | 94 |
Daya Tanjak (tan Ø) | 24.0 | |
MESIN | Model | J08E-UG |
Tipe | Diesel 4 Stroke; In-Line | |
Tenaga Maks (PS/rpm) | 235 / 2500 | |
Momen Putir Maks. (Kgm/rpm) | 72 / 1500 | |
Jumlah Silinder | 6 | |
Diameter x Langkah Piston (mm) | 112 x 130 | |
Isi Silinder | 7684 | |
KOPLING | Tipe | Single Dry Plate, with Coil Spring |
Diameter | 380 | |
TRANSMISI | Tipe | 6 speeds |
Perbanding Gigi | - | |
ke-1 | 8.189 | |
ke-2 | 5.34 | |
ke-3 | 3.076 | |
ke-4 | 1.936 | |
ke-5 | 1.341 | |
ke-6 | 1 | |
ke-7 | - | |
ke-8 | - | |
ke-9 | - | |
mundur | 7.142 | |
KEMUDI | Tipe | Integral Power Steering |
Radius Putar Min. (m) | 8.4 | |
SUMBU | Depan | Reverse Elliot, I-Section Beam |
Belakang | Full floating type with hypoid gear | |
Perbandingan gigi akhir | STD = 5.857 | |
Sistem Penggerak | Rear 6x2 | |
REM | Rem Utama | Air Over Hydraulic, with Two Circuit |
Rem Pelambat | With on Exhaust Pipe | |
Rem Parkirr | Internal Expanding tipe pada transmisi output | |
RODA & BAN | Ukuran Rim | 20X7.00T-162 |
Ukuran Ban | 10.00-20-16PR | |
Jumlah Ban | 10 | |
SISTIM LISTRIK | Accu | 12V-65Ah x2 |
TANGKI SOLAR | Kapasitas (L) | 200 |
DIMENSI (mm) | Jarak Sumbu Roda | 4130+1300 |
Panjang bak | 6420 | |
Total Panjang | 8480 | |
Total Lebar | 2460 | |
Total Tinggi | 2695 | |
Lebar Jejak Depan FR Tr | 1925 | |
Lebar jejak Belakang RR Tr | 1855 | |
Julur Depan FPH | 1255 | |
Julur Belakang ROH | 1795 | |
SUSPENSI | Depan & Belakang | Rigid Axle with Semi Elliptic Leaf Spring |
BERAT CHASSIS (kg) | Depan | 2845 |
Belakang | 3365 | |
Berat Kosong | 6210 | |
GVWR | 26000 | |
HARGA SRP OFF THE ROAD SURABAYA | BY Phone 031 - 70000603 | |
TIPE KAROSERI | Dump | - |
Mobil Boks | O | |
Boks Berpendingin | O | |
Bak Terbuka | O | |
Crane | O | |
Mobil Derek | - | |
Sky Lift | - | |
Tangki | O | |
Los Bak | O | |
Angkut Kendaraan | O | |
Truk Logging | - | |
Molen | - | |
Tangki High Blow | O | |
Arm Roll | - | |
Mobil Pemadam | - | |
Ambulance | - | |
Truk Sampah | - | |
Mobil Penarik | - |
