RANGER FG 235 JL
SPESIFIKASI
| PRODUK | Model | FG 235 JL |
| PRODUKSI | Kode Produksi | FG8JKKB-GGJL * |
| PERFORMANCE | Kecepatan Maksimum(km/jam) | 94 |
| Daya Tanjak (tan Ø) | 44.9 | |
| MESIN | Model | J08E-UG |
| Tipe | Diesel 4 Stroke; In-Line | |
| Tenaga Maks (PS/rpm) | 235 / 2500 | |
| Momen Putir Maks. (Kgm/rpm) | 72 / 1500 | |
| Jumlah Silinder | 6 | |
| Diameter x Langkah Piston (mm) | 112 x 130 | |
| Isi Silinder | 7684 | |
| KOPLING | Tipe | Single Dry Plate, with Coil Spring |
| Diameter | 380 | |
| TRANSMISI | Tipe | MF06S |
| Perbanding Gigi | - | |
| ke-1 | 8.189 | |
| ke-2 | 5.34 | |
| ke-3 | 3.076 | |
| ke-4 | 1.936 | |
| ke-5 | 1.341 | |
| ke-6 | 1 | |
| ke-7 | - | |
| ke-8 | - | |
| ke-9 | - | |
| mundur | 7.142 | |
| KEMUDI | Tipe | Integral Power Steering |
| Radius Putar Min. (m) | 8.2 | |
| SUMBU | Depan | Reverse Elliot, I-Section Beam |
| Belakang | Full floating type with hypoid gear | |
| Perbandingan gigi akhir | STD = 5.857 | |
| Sistem Penggerak | Rear 4x2 | |
| REM | Rem Utama | Air Over Hydraulic, with Two Circuit |
| Rem Pelambat | With on Exhaust Pipe | |
| Rem Parkirr | Internal Expanding tipe pada transmisi output | |
| RODA & BAN | Ukuran Rim | 20X7.00T-162 |
| Ukuran Ban | 10.00-20-16PR | |
| Jumlah Ban | 6 | |
| SISTIM LISTRIK | Accu | 12V-65Ah x2 |
| TANGKI SOLAR | Kapasitas (L) | 200 |
| DIMENSI (mm) | Jarak Sumbu Roda | 4850 |
| Panjang bak | 6495 | |
| Total Panjang | 8555 | |
| Total Lebar | 2425 | |
| Total Tinggi | 2625 | |
| Lebar Jejak Depan FR Tr | 1915 | |
| Lebar jejak Belakang RR Tr | 1820 | |
| Julur Depan FPH | 1235 | |
| Julur Belakang ROH | 2470 | |
| SUSPENSI | Depan & Belakang | Rigid Axle with Semi Elliptic |
| BERAT CHASSIS (kg) | Depan | 2710 |
| Belakang | 1955 | |
| Berat Kosong | 4665 | |
| GVWR | 15100 | |
| HARGA SRP OFF THE ROAD SURABAYA | By Phone 031-70000603 | |
| TIPE KAROSERI | Dump | - |
| Mobil Boks | O | |
| Boks Berpendingin | O | |
| Bak Terbuka | O | |
| Crane | O | |
| Mobil Derek | - | |
| Sky Lift | O | |
| Tangki | O | |
| Los Bak | O | |
| Angkut Kendaraan | O | |
| Truk Logging | - | |
| Molen | - | |
| Tangki High Blow | O | |
| Arm Roll | - | |
| Mobil Pemadam | O | |
| Ambulance | - | |
| Truk Sampah | - | |
| Mobil Penarik | - | |
